12”X30’ 2 sections
24” you have 22’ available
60” X 75" We have 8 Sections and 1 Pusher
72” x 75" We have 54 Sections
84” x 76" We have 18 Sections and 3 Pushers
The measurements of the width from the outside most of the C-channel.
LOWER STACKER DISCHARGE ( measured outside of frame to outside of frame)
87" wide x 78" long (3)
87" wide x 84" long (1)
87" wide x 60" long (6)
UPPER STACKER DISCHARGE
99-1/2" wide x 78" long (10)
99-1/2" wide x 60" long (6)
MAIN LINE
99-1/2" x 48" long (1)
99-1/2" wide x 51" (1)
99-1/2" wide x 54" (1)
99-1/2" wide x 57" (1)
99-1/2" wide x 59" (1)
99-1/2" wide x 60" (10)
99-1/2" wide x 78" (5)
99-1/2" wide x 81" (1)
99-1/2" wide x 90" (1)
99-1/2" wide x 90" (1)
99-1/2" wide x 120" (1)
100-1/4 wide x 51" (1)
100-1/4 wide x 51" (1)
DISPATCH LINES ( there are four)
87-1/2" wide x 66" long (4)
87-1/2" wide x 78" long (12)
PUSHERS for the Dispatch Lines ( there are four)
126" wide x 84" long (4)
BLUE TOP BELT CONVEYORS ( there are four)
100" wide x 84" long (2)
100" wide x 144" long (1)
100" wide x 156" long (1)
TOP DUNNAGE INSERTER ( clamp bar area)
99-1/2" wide x 123 long (2)
BOTTOM DUNNAGE INSERTER ( clamp bar area)
99-1/2" wide x 123" long (1)
MISC. CONVEYORS
99-1/2" wide x 36" long (1)
99-1/2" wide x 51" long (1)
99-1/2" wide x 60" long (1)
99-1/2" wide x 78" long (3)
* CAN BE SOLD SEPARATELY!! |
